ELK Stack Cheatsheet

1. Introduction:

• The ELK Stack is a powerful suite of open-source tools: Elasticsearch for search and analytics, Logstash for data processing, and Kibana for visualization. It's often extended with Beats for data collection and X-Pack for additional features.

2. Elasticsearch:

• Installing Elasticsearch:

  wget https://artifacts.elastic.co/downloads/elasticsearch/elasticsearch-7.10.2-x86_64.rpm
  sudo rpm -ivh elasticsearch-7.10.2-x86_64.rpm
  sudo systemctl start elasticsearch
  sudo systemctl enable elasticsearch

• Basic Configuration:

  • Edit /etc/elasticsearch/elasticsearch.yml:

  network.host: localhost
  http.port: 9200

• Basic Queries:

  curl -X GET "localhost:9200/_cat/indices?v"
  curl -X GET "localhost:9200/my-index/_search?q=user:john"

• Indexing Documents:

  curl -X POST "localhost:9200/my-index/_doc/1" -H 'Content-Type: application/json' -d'
  {
    "user": "john",
    "message": "Hello, Elasticsearch!"
  }'

• Elasticsearch Cluster:

  • Configure multi-node clusters by setting cluster.name, node.name, and discovery.seed_hosts in elasticsearch.yml.

3. Logstash:

• Installing Logstash:

  wget https://artifacts.elastic.co/downloads/logstash/logstash-7.10.2.rpm
  sudo rpm -ivh logstash-7.10.2.rpm
  sudo systemctl start logstash
  sudo systemctl enable logstash

• Logstash Configuration:

  input {
    file {
      path => "/var/log/syslog"
      start_position => "beginning"
    }
  }
  filter {
    grok {
      match => { "message" => "%{SYSLOGLINE}" }
    }
  }
  output {
    elasticsearch {
      hosts => ["localhost:9200"]
      index => "syslog-%{+YYYY.MM.dd}"
    }
  }

• Running Logstash:

  sudo systemctl start logstash

• Using Beats with Logstash:

  • Use Filebeat, Metricbeat, or Packetbeat to ship data to Logstash for processing.

4. Kibana:

• Installing Kibana:

  wget https://artifacts.elastic.co/downloads/kibana/kibana-7.10.2-x86_64.rpm
  sudo rpm -ivh kibana-7.10.2-x86_64.rpm
  sudo systemctl start kibana
  sudo systemctl enable kibana

• Basic Configuration:

  • Edit /etc/kibana/kibana.yml:

  server.port: 5601
  server.host: "localhost"
  elasticsearch.hosts: ["http://localhost:9200"]

• Creating Visualizations:

  1. Navigate to Visualize in the Kibana interface.
  2. Choose a visualization type (e.g., line chart, pie chart).
  3. Select the data source and configure your queries.
  4. Save and add the visualization to a dashboard.

• Kibana Dashboards:

  • Use dashboards to combine multiple visualizations into a single view, useful for monitoring and analysis.

5. Beats:

• Filebeat:

  • Installing Filebeat:

    wget https://artifacts.elastic.co/downloads/beats/filebeat/filebeat-7.10.2-x86_64.rpm
    sudo rpm -ivh filebeat-7.10.2-x86_64.rpm
    sudo systemctl start filebeat
    sudo systemctl enable filebeat

  • Configuring Filebeat:

    filebeat.inputs:
    - type: log
      paths:
        - /var/log/syslog

    output.elasticsearch:
      hosts: ["localhost:9200"]

  • Running Filebeat:

    sudo systemctl start filebeat

• Metricbeat:

  • Collects metrics from the system and services like MySQL, Docker, etc.

• Packetbeat:

  • Captures network traffic and analyzes protocols.

6. Security in ELK Stack:

• Enabling HTTPS in Elasticsearch:

  xpack.security.enabled: true
  xpack.security.http.ssl.enabled: true
  xpack.security.http.ssl.keystore.path: /path/to/keystore.jks

• User Authentication:

  • Use X-Pack to manage users, roles, and permissions.

7. ELK Stack in Kubernetes:

• Deploying ELK Stack:
  • Use Helm charts to deploy the ELK stack in Kubernetes for easier management and scaling.

8. Troubleshooting ELK Stack:

• Common Issues:
  • High Memory Usage: Optimize the heap size in Elasticsearch.
  • Logstash Performance: Tune pipeline workers

and batch size.

• Debugging:
  • Check logs for Elasticsearch (/var/log/elasticsearch/), Logstash (/var/log/logstash/), and Kibana (/var/log/kibana/).
  • Use curl to test Elasticsearch endpoints and ensure services are running.
