Prometheus Cheatsheet

1. Introduction:

• Prometheus is an open-source systems monitoring and alerting toolkit, particularly well-suited for monitoring dynamic, cloud-native environments such as Kubernetes. It uses a pull-based model to scrape metrics from configured endpoints.

2. Key Concepts:

• Metrics: Data points collected over time, usually in the form of time series.
• PromQL: Prometheus Query Language used to query the collected metrics.
• Exporters: Components that expose metrics in a format that Prometheus can scrape.
• Alertmanager: Manages alerts generated by Prometheus.

3. Installation:

• Running Prometheus:

  wget https://github.com/prometheus/prometheus/releases/download/v2.30.0/prometheus-2.30.0.linux-amd64.tar.gz
  tar xvfz prometheus-*.tar.gz
  cd prometheus-*
  ./prometheus --config.file=prometheus.yml

• Docker:

  docker run -p 9090:9090 prom/prometheus

4. Prometheus Configuration:

• Basic prometheus.yml Configuration:

  global:
    scrape_interval: 15s

  scrape_configs:
    - job_name: 'prometheus'
      static_configs:
        - targets: ['localhost:9090']

• Adding Targets:

  - job_name: 'node_exporter'
    static_configs:
      - targets: ['localhost:9100']

5. Prometheus Query Language (PromQL):

• Basic Queries:

  up
  rate(http_requests_total[5m])


• Aggregations:

  sum(rate(http_requests_total[5m]))
  avg_over_time(http_requests_total[5m])


• Recording Rules:

  groups:
  - name: example
    rules:
    - record: job:http_inprogress_requests:sum
      expr: sum(http_inprogress_requests) by (job)

6. Exporters:

• Node Exporter: Collects system-level metrics.

  wget https://github.com/prometheus/node_exporter/releases/download/v1.2.2/node_exporter-1.2.2.linux-amd64.tar.gz
  tar xvfz node_exporter-*.tar.gz
  ./node_exporter

• Custom Exporter: Writing a custom exporter using Python.

  from prometheus_client import start_http_server, Gauge
  import random
  import time

  g = Gauge('random_number', 'A random number')

  def generate_random_number():
      while True:
          g.set(random.random())
          time.sleep(5)

  if __name__ == '__main__':
      start_http_server(8000)
      generate_random_number()

7. Alerts and Alertmanager:

• Alerting Rules:

  groups:
  - name: example
    rules:
    - alert: HighMemoryUsage
      expr: node_memory_Active_bytes / node_memory_MemTotal_bytes * 100 > 90
      for: 5m
      labels:
        severity: critical
      annotations:
        summary: "High memory usage detected on {{ $labels.instance }}"
        description: "Memory usage is above 90% for more than 5 minutes."

• Alertmanager Configuration:

  global:
    resolve_timeout: 5m

  route:
    group_by: ['alertname']
    receiver: 'email'

  receivers:
  - name: 'email'
    email_configs:
    - to: 'your-email@example.com'
      from: 'prometheus@example.com'
      smarthost: 'smtp.example.com:587'
      auth_username: 'username'
      auth_password: 'password'

8. Prometheus Federation:

• Setting Up Federation:

  scrape_configs:
  - job_name: 'federate'
    honor_labels: true
    metrics_path: '/federate'
    params:
      match[]:
        - '{job="prometheus"}'
    static_configs:
      - targets:
        - 'prometheus-server-1:9090'
        - 'prometheus-server-2:9090'

9. Monitoring Kubernetes with Prometheus:

• Deploying Prometheus on Kubernetes:

  apiVersion: monitoring.coreos.com/v1
  kind: Prometheus
  metadata:
    name: prometheus
  spec:
    replicas: 1
    serviceAccountName: prometheus
    serviceMonitorSelector:
      matchLabels:
        team: frontend
    resources:
      requests:
        memory: 400Mi
    storage:
      volumeClaimTemplate:
        spec:
          storageClassName: standard
          resources:
            requests:
              storage: 50Gi

• ServiceMonitor Example:

  apiVersion: monitoring.coreos.com/v1
  kind: ServiceMonitor
  metadata:
    name: example-monitor
  spec:
    selector:
      matchLabels:
        app: example
    endpoints:
      - port: web

10. Advanced Prometheus Concepts:

• Thanos: Extends Prometheus with long-term storage, global querying, and downsampling.
• Cortex: Multi-tenant, horizontally scalable Prometheus as a service.

11. Prometheus Security:

• Basic Authentication:

  basic_auth:
    username: admin
    password: admin

• TLS/SSL Configuration:

  tls_config:
    ca_file: /etc/prometheus/certs/ca.crt
    cert_file: /etc/prometheus/certs/prometheus.crt
    key_file: /etc/prometheus/certs/prometheus.key

12. Troubleshooting Prometheus:

• Common Issues:

  • High Cardinality Metrics: Too many unique time series can overwhelm Prometheus.
  • Slow Queries: Optimize queries by avoiding high cardinality and using efficient aggregations.

• Debugging:

  • Use the promtool command-line tool to check configuration files.
  • Prometheus UI provides an interface to debug queries and examine time series data.
